Vapor Cooling Chamber Heat Sink

Vapor Cooling Chamber Heat sink is constructed from sealed copper plates and filled with a small amount of fluid such as deionized water that allows heat to be rapidly dispersed away from the source. Inside the chamber resides an internal support structure to prevent the buckling of chamber walls. Classified formally as a heatpipe, a copper vapor chamber is one of the best heat spreading options at the base of a heatsink; and typically used for high power devices. When combined with stamped fins, it creates a high-end thermal management device that can rapidly spread heat from a small source to a large surface area.

PT heatsink is one of the leading custom vapor cooling chamber heat sink manufacturer in China, we have produced vapor chamber heat sink with stacked fin, vapor chamber heat sink with CNC machined

Latest Project

The Process Flow of Custom Vapor Chamber Heat Sink

01. Powder Filling
02. Sintering
03. Remove Powder Fill Jig
04. Forming
05. Insert Supported Layer
06. Forming
07. Brazing
vapor-chamber-with-stack-fin
08. Leakage Test
09. Fill & Vacuum
10. Tail Welding
11. Forming
12. Aging
13. Q-Load
14. Soldering to fin/baseplate

Vapor Cooling Chamber Heat Sink Thermal Performance

VC Th'k mm Evaporation (Th'k mm) Condenser (Th'k mm) Wick Structure Q-Max (W)
3.0 1 0.6 Sintering Powder 300
2.5 0.8 0.6 Sintering Powder 250
2.3 0.8 0.6 coating+sintering powder 250
2.0 0.6 0.6 Coating+sintering powder 200
1.6 0.4 0.4 Mesh+Groove 200
1.2 0.2 0.2 Mesh+Groove 200
0.6 0.15 0.15 Mesh + Groove 10

Types of Vapor Cooling Chamber Heat Sink

Vapor Cooling Chamber Heat Sink Design Guide
